Hand-held DC controller

A bi-directional variable speed DC motor controller which provides cost-effective, 'plug & play' single-axis remote control of manipulation products including MagiDrives and Linear Shift Mechanisms.

UHV Design’s DC motor controller has been developed to offer simple, single-axis remote control of its manipulation products.

Read more

Key features

  • Brushless DC motor technology for longer life

  • Full torque from 100 to 3000 rpm

  • Smooth running even at low speeds

  •  50W power output
  • Universally-rated to ensure voltage compatibility

Show me more key features

The control interface module with both speed and direction controls, can be plugged into the motor directly. Alternatively an extension cable can be utilised for remote control. The control interface can then take two inputs for limit switches, thus preventing over-drive in either direction. The hand-held DC motor controller provides a simple costeffective solution to DC motorisation.

The system has the advantage over many conventional variable voltage supplies in that it is a true speed controller and gives full torque throughout the speed range. It has particularly smooth running characteristics (even at slow speeds). Universally-rated to ensure voltage compatibility, the controller is fully compliant with EMC test regulations and carries the CE mark. The DC Motor controller is only specified for DC motor driven components it has been supplied with. This will ensure product
compatibility.

MagiDrive Rotary Motion Controller (SADC-B)

Simple hand-held control of rotation speed and direction for the MagiDrive range of magnetically-coupled drives.

The SADC-B includes:

  • Base model and extension cable:
  • Brushless DC servo motor
  • Direction and speed control module
  • Switch mode AC Power Supply Unit
  • Control module extension cable



Linear Shift Mechanism Motion Controller (SADC-D)

Simple hand-held control of linear speed and direction for the LSM range of linear shift mechanisms.

The SADC-D includes:

  • Base model with limit switch cable:
  • Brushless DC servo motor
  • Direction and speed control module
  • Switch mode AC Power Supply Unit
  • Limit Switch signal control cable

Note: must be purchased with Linear Shift Mechanism

  For more information please contact us.
