Surface Science

For contamination and interference-free analysis

UHV Design’s analytical stages provide up to 5 axes of motion, offering unmatched accuracy in surface science experiments.

Configurable for specific requirements

We provide a range of UHV compatible sample transfer devices. These are developed specifically to ensure the reliable and repeatable transfer of common sample holders, e.g. flag and pucks. Crucially, our sample manipulators are modular so they can be configured to meet specific application requirements.

Key features

Full motorisation
Addition of encoders (incremental or absolute)
Resistive heating up to 900 °C
EB heating up to 1200 °C
Liquid nitrogen cooling to -160 °C
Liquid helium cooling to 20K

Secure Sample Transfer Options

Transfer Arms

Secure sample transfer with high-performance magnetically-coupled transfer arms
Extensive range to transfer specific industry-standard sample holders using a variety of actuation methods
Standard transfer lengths up to 1,219mm
Custom options are available

View category

Wobble Sticks

Slimline magnetically-coupled modular design with +/-22° tilt
Choice of end effectors for flag, puck and esca stub
Up to 350mm in standard lengths.
Custom options are available

View category

Sample Manipulators

Our high precision stages have been designed to address the ever-increasing demands of today's surface analytical and synchrotron end-station applications. Offering high precision and rigidity, our range of sample manipulators can be configured with a range of options for X, Y, Z and sample rotations (R1 & R2). Additionally, we also offer the choice of actuation and control options:

If you would like to discuss your project with our engineering team, please contact us.
